The TAC338 is specifically designed for cartridges with a .585″ rim diameter such as the .416 Rigby, the 338 Lapua Magnum or the 378 Weatherby based cartridges. The TAC338 is also 0.050" larger in diameter and 0.465" longer than the standard TAC action. That is needed to accommodate the 0.750 diameter bolt that is necessary for these cartridges. The TAC338 actions have no feed lips and use only center feed box magazines. The TAC338 actions use a straight bolt handle with a threaded bolt knob. It comes standard with a small tac knob that can be swapped with aftermarket bolt knobs by the user or a gunsmith. One piece picatinny rails with 0, 20 and 40 moa cant are available. The bolts have a new proprietary coating that makes them as smooth as glass.

SPECS:

• Right hand bolt, right hand port
• Receiver Material: 416 Stainless hardened to 42 Rockwell
• Receiver Length: 9.165”
• Receiver Diameter: TAC338 – 1.40”
• Headspace: .1.000” Headspace tolerance is held to +/- .001”
• Tenon threads: Threads are made with a single point boring bar and indexed to top center of action. This allows any barrel ever fitted to a Stiller Action to be screwed onto any other Stiller Action without need for re-headspacing or re-indexing.
• Bolt Face: 338 Lapua/378 Weatherby
• Bolt Design: .750” diameter one piece fluted on top and sides but not the bottom so that flutes will not interfere with magazine lips. TAC actions have straight bolt handle. Bolt knob is threaded and comes equipped with a small TAC knob. Aftermarket knobs can be swapped out by user or gunsmith.
• Bolt Stop: On side of receiver opposite bolt handle above the stock line
• Bolt Throw: 90 degree
• Bolt Material: Chrome Molly hardened to 42 Rockwell
• Bolt Coating: Proprietary double layer coating makes them as smooth as glass
• Firing Pin: Fluted Stainless Steel, .068 diameter tip, Chrome silicon spring
• Extractor/Ejector: Modified M16 type extractor, Rem 700 style pin ejector
• Recoil Lug: 416R Stainless parallel sided or tapered. .187” (Rem700 standard) or .300” produced in house and surface ground to .0002” tolerance.

TENON DRAWING:

***MUST SHIP TO A FFL***

• Red Hawk Rifles LLC. will transfer ownership of any firearm/receiver ONLY to individuals or agencies in possession of a valid Federal Firearms License (FFL). We cannot ship to individuals without a valid FFL.
• It is the buyer’s responsibility to check and comply with local, state, and federal laws. The buyer assumes all legality, liability and responsibility for the condition, use & security/storage of the firearm/receiver purchased.
• It is the buyer’s responsibility to contact the FFL dealer. Be aware that it is customary for your local dealer to charge a transaction fee at the time you pick up your purchase. This transfer fee is strictly between you and your local dealer. It is your responsibility to check with your local dealer concerning any policy of this kind and concerning your obligations.
• You the buyer are responsible for forwarding a copy of the FFL and all pertinent contact information to Red Hawk Rifles LLC. FFL’s can be sent to:
